Structure and characteristics:
This series adopts polytetrafluoroethylene sealing and is equipped with a pressure spring as an automatic compensation device for thermal expansion and contraction. There are two sets of disconnected channels drilled on the graphite block, and these two sets are at right angles. Two different fluids achieve heat exchange through these two channels. The system adopts advanced processing technology, which has advantages such as high heat transfer efficiency, stability and reliability, impact resistance, and convenient maintenance**** The heat exchange area can reach 800 square meters.
Technical characteristics:
Permissible temperature: -40-220 ℃
Permissible pressure: ≤ 0.4MPa
Note: 0.6-1MPa can also be manufactured
|
